Fixing & Sealing

ES1131B
ES2044P
ES2331W
ES2482W

Key Properties	Units	ES1131B
Material Type	-	Silicone
One or Two-Part	-	One
Curing Type	-	Room temperature
Color	-	Black
Specific Gravity	g/cm3	1.11
Tack-Free Time	minutes	15
Hardness	Shore	A 60
Tensile Strength	MPa	1.8
Elongation	%	200
Shear Strength (AL)	MPa	1.5
Volume Resistivity	Ω.cm	1.0×10¹⁴
Dielectric Strength	kv/mm	20
Dielectric Constant (50Hz)	-	4.0
Dielectric Loss (50Hz)	-	0.10
Volatile Siloxane(D3~D10)	ppm	-
UL Flame Retardancy	-	-
Curing Time	-	25℃*7days

Key Properties	Units	ES2044P
Material Type	-	Silicone
One or Two-Part	-	One
Curing Type	-	Room temperature
Color	-	White
Specific Gravity	g/cm3	1.38
Tack-Free Time	minutes	5
Hardness	Shore	A 65
Tensile Strength	MPa	2.0
Elongation	%	50
Shear Strength (AL)	MPa	2.0
Volume Resistivity	Ω.cm	1.0×10¹³
Dielectric Strength	kv/mm	-
Dielectric Constant (50Hz)	-	4.7
Dielectric Loss (50Hz)	-	0.20
Volatile Siloxane(D3~D10)	ppm	< 150
UL Flame Retardancy	-	UL 94 V-0
Curing Time	-	25℃*7days

Key Properties	Units	ES2331W
Material Type	-	Silicone
One or Two-Part	-	One
Curing Type	-	Room temperature
Color	-	White
Specific Gravity	g/cm3	1.0
Tack-Free Time	minutes	10
Hardness	Shore	A 30
Tensile Strength	MPa	0.6
Elongation	%	110
Shear Strength (AL)	MPa	0.6
Volume Resistivity	Ω.cm	1.0×10¹³
Dielectric Strength	kv/mm	20
Dielectric Constant (50Hz)	-	50
Dielectric Loss (50Hz)	-	0.1
Volatile Siloxane(D3~D10)	ppm	< 300
UL Flame Retardancy	-	-
Curing Time	-	25℃*7days

Key Properties	Units	ES2482W
Material Type	-	Silicone
One or Two-Part	-	One
Curing Type	-	Room temperature
Color	-	White
Specific Gravity	g/cm3	1.40
Tack-Free Time	minutes	10
Hardness	Shore	A 68
Tensile Strength	MPa	2.0
Elongation	%	40
Shear Strength (AL)	MPa	1.8
Volume Resistivity	Ω.cm	1.0×10¹³
Dielectric Strength	kv/mm	20
Dielectric Constant (50Hz)	-	6.5
Dielectric Loss (50Hz)	-	0.28
Volatile Siloxane(D3~D10)	ppm	< 150
UL Flame Retardancy	-	UL 94 V-0
Curing Time	-	25℃*7days

※ For more product specifications, please contact your salesperson or agent.
