Epoxy

YS1003 A&B
YS2003B
YS4010G

Key Properties	Units	YS1003 A&B
Material Type	-	Epoxy
One or Two-Part	-	Two
Curing Type	-	Heat curing
Mix Ratio	-	4:1
Color	-	Black
Viscosity (Part A)	cP	2000
Viscosity (Part B)	cP	200
Viscosity (Mixed)	cP	1500
Specific Gravity	g/cm3	1.2
Working Time (25℃)	minutes	120
Hardness	Shore	D 75
Shear Strength (Al)	MPa	23
Shear Strength (Glass)	MPa	-
Volume Resistivity	Ω.cm	UL 94 V-0
Dielectric Strength	kV/mm	23
Dielectric Constant (50Hz)	-	4.1
Dielectric Loss (50Hz)	-	0.023
UL Flame Retardancy	-	UL 94 V-0
Curing Time	minutes	60℃*60

Key Properties	Units	YS2003B
Material Type	-	Epoxy
One or Two-Part	-	One
Curing Type	-	Heat curing
Mix Ratio	-	-
Color	-	Black
Viscosity (Part A)	cP	-
Viscosity (Part B)	cP	-
Viscosity (Mixed)	cP	70000
Specific Gravity	g/cm3	1.51
Working Time (25℃)	minutes	-
Hardness	Shore	D 80
Shear Strength (Al)	MPa	2.6
Shear Strength (Glass)	MPa	-
Volume Resistivity	Ω.cm	UL 94 V-0
Dielectric Strength	kV/mm	21
Dielectric Constant (50Hz)	-	-
Dielectric Loss (50Hz)	-	-
UL Flame Retardancy	-	UL 94 V-0
Curing Time	minutes	130℃*120

Key Properties	Units	YS4010G
Material Type	-	Epoxy
One or Two-Part	-	One
Curing Type	-	Heat curing
Mix Ratio	-	-
Color	-	Grey
Viscosity (Part A)	cP	-
Viscosity (Part B)	cP	-
Viscosity (Mixed)	cP	100000
Specific Gravity	g/cm3	1.10
Working Time (25℃)	minutes	-
Hardness	Shore	D 65
Shear Strength (Al)	MPa	3.5
Shear Strength (Glass)	MPa	-
Volume Resistivity	Ω.cm	UL 94 V-0
Dielectric Strength	kV/mm	10
Dielectric Constant (50Hz)	-	9.0
Dielectric Loss (50Hz)	-	0.6
UL Flame Retardancy	-	-
Curing Time	minutes	120℃*70

※ For more product specifications, please contact your salesperson or agent.
