UV Adhesive







FEATURES

UV+Heat cure silicone encapsulation reduces 90% process time

Prevent component damage from sulfur and moisture

The fastest UV LED encapsulant in the world








FEATURES

UV+Heat cure silicone encapsulation reduces 90% process time

Prevent component damage from sulfur and moisture

The fastest UV LED encapsulant in the world


Key Properties Units

EV1085Y

   Material Type

-

Acrylic

   One or Two-Part

-

One

   Curing Type

-

UV curing

   Mix Ratio

-

-

   Color

-

Transparent

   Viscosity

cP

18000

   Solids Content

%

-

   Specific gravity

g/cm3

1.05

   Hardness

Shore

D 67

   Tensile Strenght

MPa

20

   Elongation

%

85

   Shear Strength (Glass)

MPa

1.5

   Volume Resistivity

Ω.cm

1.0×1012

   Dielectric Strength

kV/mm

20

   Dielectric Constant (50Hz)

-

6.5

   Dielectric Loss (50Hz)

-

0.2

   Curing Time

-

-

Key Properties Units

EV2031C

   Material Type

-

Acrylic

   One or Two-Part

-

One

   Curing Type

-

UV curing

   Mix Ratio

-

-

   Color

-

Transparent

   Viscosity

cP

650

   Solids Content

%

100

   Specific gravity

g/cm3

1.02

   Hardness

Shore

A 84

   Tensile Strenght

MPa

4.0

   Elongation

%

80

   Shear Strength (Glass)

MPa

0.8

   Volume Resistivity

Ω.cm

1.0×1013

   Dielectric Strength

kV/mm

20

   Dielectric Constant (50Hz)

-

6.0

   Dielectric Loss (50Hz)

-

0.2

   Curing Time

-

4000mJ/cm2
(UV LED 365nm)

Key Properties Units

EV2351Y

   Material Type

-

Acrylic

   One or Two-Part

-

One

   Curing Type

-

UV curing

   Mix Ratio

-

-

   Color

-

Transparent

   Viscosity

cP

3200

   Solids Content

%

100

   Specific gravity

g/cm3

1.07

   Hardness

Shore

D 60

   Tensile Strenght

MPa

10

   Elongation

%

30

   Shear Strength (Glass)

MPa

2.5

   Volume Resistivity

Ω.cm

1.0×1013

   Dielectric Strength

kV/mm

18

   Dielectric Constant (50Hz)

-

5.0

   Dielectric Loss (50Hz)

-

0.1

   Curing Time

-

3000 mJ/cm2
(UV Mercury lamp)

  For more product specifications, please contact your salesperson or agent.
