Conformal Coating







Conformal coating materials are typically

Applied as a thin layer across the surface of

Electronic circuit boards, acting as protection

Against external influences, such as weather, moisture, dust, temperature fluctuations and mechanical stress.



Curing systems include room temperature,

Heat and UV curing.



CSI CHEMICAL offers a variety of products.

Details of silicone and acrylic coating materials

Which can be applied by brushing, spraying,

or dipping.







FEATURES

Room temperature or heat cure

Resistance to temperature extremes

Primer-less adhesion to many substrates

Excellent controlled volatility of low molecular weight

Excellent electrical insulation properties





Conformal coating materials are typically

Applied as a thin layer across the surface of

Electronic circuit boards, acting as protection

Against external influences, such as weather,

moisture, dust, temperature fluctuations

and mechanical stress.



Curing systems include room temperature,

Heat and UV curing.



CSI CHEMICAL offers a variety of products.

Details of silicone and acrylic coating materials

Which can be applied by brushing, spraying,

or dipping.





FEATURES



Room temperature or heat cure

Resistance to temperature extremes

Primer-less adhesion to many substrates

Excellent controlled volatility of low molecular weight

Excellent electrical insulation properties





Key Properties Units

EP2571 C A&B

   Material Type

-

Epoxy

   One or Two-Part

-

Two

   Curing Type

-

Heat curing

   Mix Ratio

-

3:1

   Color

-

Translucent

   Viscosity (Mixed)

cP

240

   Specific Gravity

g/cm3

1.09

   Tack-Free Time

minutes

50

   Hardness

Shore

A 68

   Tensile Strength

MPa

8

   Elongation

%

50

   Shear Strength (AL)

MPa

2.50

   Volume Resistivity

Ω.cm

1.0×1011

   Dielectric Strength

kV/mm

20

   Dielectric Constant (50Hz)

-

7.5

   Dielectric Loss (50Hz)

-

0.20

   Volatile Siloxane(D3~D10)

ppm

-

   UL Flame Retardancy

-

UL 94 V-0

   Curing Time

-

50℃*2hours

Key Properties Units

ES772BL

   Material Type

-

Silicone

   One or Two-Part

-

One

   Curing Type

-

Room temperature

   Mix Ratio

-

-

   Color

-

Translucent

   Viscosity (Mixed)

cP

350

   Specific Gravity

g/cm3

0.95

   Tack-Free Time

minutes

15

   Hardness

Shore

A 85

   Tensile Strength

MPa

1.0

   Elongation

%

300

   Shear Strength (AL)

MPa

0.8

   Volume Resistivity

Ω.cm

1.0×1014

   Dielectric Strength

kV/mm

18

   Dielectric Constant (50Hz)

-

5.0

   Dielectric Loss (50Hz)

-

0.1

   Volatile Siloxane(D3~D10)

ppm

<300

   UL Flame Retardancy

-

-

   Curing Time

-

25℃*7days

Key Properties Units

ES762BL

   Material Type

-

Silicone

   One or Two-Part

-

One

   Curing Type

-

Room temperature

   Mix Ratio

-

-

   Color

-

Translucent

   Viscosity (Mixed)

cP

1000

   Specific Gravity

g/cm3

0.94

   Tack-Free Time

minutes

10

   Hardness

Shore

A 20

   Tensile Strength

MPa

0.2

   Elongation

%

65

   Shear Strength (AL)

MPa

0.30

   Volume Resistivity

Ω.cm

1.0×1013

   Dielectric Strength

kV/mm

17

   Dielectric Constant (50Hz)

-

4

   Dielectric Loss (50Hz)

-

0.04

   Volatile Siloxane(D3~D10)

ppm

<150

   UL Flame Retardancy

-

UL 94 V-0

   Curing Time

-

25℃*7days

  For more product specifications, please contact your salesperson or agent.
