Acrylic

	FEATURES ▌Rapid curing at room temperature ▌Suitable for extreme temperature resistance ▌Suitable for primer-free bonding of multiple substrates ▌Non-corrosive to metals ▌One part, no mixing required, easy to use


	FEATURES ▌Rapid curing at room temperature ▌Suitable for extreme temperature resistance ▌Suitable for primer-free bonding of multiple substrates ▌Non-corrosive to metals ▌One part, no mixing required, easy to use

EC8089C
EC8091B
EC8096 BLUE

Key Properties	Units	EC8089C
Material Type	-	Acrylic
One or Two-Part	-	One
Curing Type	-	Room temperature
Color	-	Transparent
Viscosity	cP	1000
Solids Content	%	33
Specific Gravity	g/cm3	0.95
Tack-Free Time	minutes	30
Hardness	Shore	A 35
Tensile Strength	MPa	-
Elongation	%	-
Volume Resistivity	Ω.cm	1.0×10¹³
Dielectric Strength	kV/mm	20
Dielectric Constant (50Hz)	-	5.0
Dielectric Loss (50Hz)	-	0.1
Curing Time	hours	25℃*12

Key Properties	Units	EC8091B
Material Type	-	Acrylic
One or Two-Part	-	One
Curing Type	-	Room temperature
Color	-	Black
Viscosity	cP	1800
Solids Content	%	25
Specific Gravity	g/cm3	0.82
Tack-Free Time	minutes	10
Hardness	Shore	A 30
Tensile Strength	MPa	1.3
Elongation	%	800
Volume Resistivity	Ω.cm	1.0×10¹⁴
Dielectric Strength	kV/mm	20
Dielectric Constant (50Hz)	-	4
Dielectric Loss (50Hz)	-	0.02
Curing Time	hours	25℃*72

Key Properties	Units	EC8096 BLUE
Material Type	-	Acrylic
One or Two-Part	-	One
Curing Type	-	Room temperature
Color	-	Blue
Viscosity	cP	800
Solids Content	%	26
Specific Gravity	g/cm3	0.82
Tack-Free Time	minutes	20
Hardness	Shore	A 65
Tensile Strength	MPa	10
Elongation	%	450
Volume Resistivity	Ω.cm	1.0×10¹⁴
Dielectric Strength	kV/mm	20
Dielectric Constant (50Hz)	-	3.5
Dielectric Loss (50Hz)	-	0.01
Curing Time	hours	25℃*72

※ For more product specifications, please contact your salesperson or agent.
